Upmarket Restaurant Sound
Distinguish Your Restaurant’s Atmosphere with the Ultimate 4-Zone Audio Solution
When it comes to creating the perfect dining experience, lighting and food are only half the equation. The right soundtrack—played at the right volume—can make or break a restaurant's ambiance. But how do you manage different vibes in the main dining room, the busy bar, the quiet patio, and the private event space?
Our premier 4-zone audio system, powered by industry-leading equipment from Bose Professional and Cloud, provides the perfect balance of high-fidelity sound, independent zone control, and effortless user operation.
Complete Control, Zone by Zone
This solution is designed specifically to offer four completely independent audio zones. This means your staff can easily select different audio sources and adjust volume levels for each specific area of the restaurant without disrupting the others.
The brain of the system is the Bose CSP-428 Digital Signal Processor (DSP). For AV integrators and managers, it offers an intuitive web interface for initial configuration. For day-to-day staff, it provides a highly customizable user interface that can be accessed directly from mobile devices over the restaurant's network.
For quick, physical control in the room, each zone can also be managed by Bose CC-2D ControlCenter digital controllers. These sleek, wall-mounted controllers are POE (Power Over Ethernet) powered and networked, allowing staff to make instant volume or source adjustments on the fly.
Streamlined Installation for a Clean Setup
Streamlined Installation for a Clean Setup
Nobody wants a messy equipment rack taking up valuable back-office space. This solution utilizes Bose's AmpLink connection, which drastically simplifies the installation process.
Instead of running bulky analog cables, a single CAT cable is all that is needed to transmit four distinct channels of high-quality audio from the DSP to the Bose P4300A amplifier. This ensures an incredibly clean equipment rack and a highly reliable connection. The amplifier then flawlessly distributes the audio out to a versatile range of Bose DesignMax (DM) speakers tailored to the acoustic needs of each zone.
Seamless Local Bluetooth Connectivity
Whether you are hosting a private party that wants to play their own playlist, or you have a guest DJ for the evening, local inputs are a must.
This system incorporates a Cloud BT-1FW Bluetooth wall plate. Mounted directly in the room, it serves as an easy-to-use local input for any Bluetooth-enabled device. The audio signal from the wall plate runs back to the main equipment rack over a standard CAT cable, where it is converted back into high-quality, line-level analog audio by a Cloud FPA-1 interface. This ensures the audio remains crystal clear, even over long cable runs.
The Complete Equipment List
To bring this 4-zone acoustic experience to life, the system utilizes the following premium components:
Bose Professional Processing & Amplification:
1x Bose P4300A Amplifier
1x Bose CSP-428 DSP
4x Bose CC-2D Networked Controllers
Bose Professional Speakers:
6x Bose DM3C (In-ceiling)
2x Bose DM8S (Surface-mount)
4x Bose DM6C (In-ceiling)
4x Bose DM3SE (Surface-mount outdoor/indoor)
Cloud Local Connectivity:
1x Cloud BT-1FW (Bluetooth Wall Plate)
1x Cloud FPA-1 (Analog Converter)
