AC Unico Dome DSPCCD Colour 540TVLCS

AC Unico Dome DSP CCD Colour Camera — 1/3" CCD 540TVL analogue dome camera body with CS mount, no lens included — for custom lens configurations in demanding lighting conditions.

This camera head is supplied without a lens, making it suitable for installations that require a specific focal length or aperture for their environment. The 1/3" DSP CCD sensor delivers 540 TVL horizontal resolution with a wide 101dB dynamic range (extendable to 120dB) for clear imaging in scenes with mixed bright and dark areas. Slow shutter extension allows usable images at 0.08 lux in near-darkness. BNC video output connects to standard DVRs and monitors. CS-mount thread accepts a wide range of commercially available lenses.

Key features

• 1/3" DSP CCD sensor — 540TVL colour resolution
• CS mount — compatible with a wide range of standard lenses
• No lens included — choose the focal length for your installation
• 101dB dynamic range (up to 120dB/17-bit)
• 0.6 lux minimum illumination (colour, F1.2)
• Slow shutter to 0.08 lux (F1.2) for near-dark conditions
• PAL and NTSC compatible
• BNC video output for DVR/monitor connection

Specifications

• Sensor: 1/3" DSP CCD
• Effective pixels: 540(H) × 460(V)
• Horizontal resolution: 540TVL
• Signal system: PAL / NTSC
• Minimum illumination: 0.6 lux at F1.2 (colour); 0.08 lux with slow shutter
• Dynamic range: 101dB (max 120dB / 17-bit)
• Lens mount: CS mount (lens not included)
• Video output: BNC (composite video)
• Power: DC 12V / 500mA
• Warranty: 1 year
