Barco ClickShareC‑5 Simple,one-click

Barco ClickShare C‑5 - Simple, One-Click Wireless Presentation for Huddle Spaces

The Barco ClickShare C-5 offers effortless, secure wireless presentation and collaboration for small meeting rooms and huddle spaces. Share content from any laptop or mobile device with just one click using the ClickShare App or native BYOD protocols.

Key Features

• Entry-level wireless presentation model
• Seamless content sharing via ClickShare App and native BYOD support
• Supports screen mirroring with AirPlay, Google Cast, and Miracast
• 100% secure, encrypted, and cloud-managed collaboration
• Compatible with Windows 10+, macOS 11+, Android 9+, and iOS 12+

Specifications

ClickShare Base Unit Dimensions

34 mm (H) x 135 mm (W) x 135 mm (D)

Power Supply

Standard 110/220 V AC plug or USB-C (only Gen2)

Power Consumption

Operational: 5-10W, Max: 24W

Weight

900 g

Operating System Compatibility

Windows 10 and higher, macOS 11 (Big Sur) and higher,
Android v9 and higher (ClickShare App),
iOS 12 and higher (ClickShare App)

Video Outputs

4K UHD (3840x2160) @ 30Hz via HDMI 1.4b or USB-C DisplayPort 1.2 (Gen2 only)

Audio Output

HDMI

USB Ports

1 x USB-A, 1 x USB-C

ClickShare Buttons

0 (App only)

ClickShare App

Available for Desktop and Mobile

Native Protocols Supported

AirPlay, Google Cast, Miracast

Maximum Simultaneous Connections

32 connections (via App and/or Buttons)

Noise Level

Max. 25 dBA @ 0-30°C
Max. 30 dBA @ 30-40°C

Authentication Protocol

WPA2-PSK in standalone mode
WPA2-PSK or IEEE 802.1X with ClickShare Button in network integration mode

Wireless Transmission Protocol

IEEE 802.11 a/g/n/ac and IEEE 802.15.1

Wireless Reach

Adjustable with signal strength modulation; max. 30 m (100 ft) between ClickShare Button and Base Unit
Frequency band: 2.4 GHz and 5 GHz

Connections

1 x Ethernet LAN 1 Gbit
1 x USB-C 2.0 (front); 1 x USB-A 2.0 (front)
Gen2: 1 x USB-C 3.0 (front); 1 x USB-A 3.0 (front)

Operating Temperature Range

0°C to +40°C (32°F to 104°F)
Max 35°C (95°F) at 3000 m altitude

Storage Temperature Range

-20°C to +60°C (-4°F to 140°F)

Humidity

Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing

Anti-theft System

Kensington lock

Certifications

FCC, CE

Touch Screen Support & Interactivity

Not supported

Room Dock (Peripheral Support)

No

Download Spec Sheet
