Global Cache IP2CCiTach Relay

Global Cache IP2CC - iTach Relay

Seamlessly connect, monitor, and control relay-activated devices over a network and the Internet with the Global Cache IP2CC iTach Relay. This Ethernet-based device offers advanced automation and control flexibility, ideal for homes, businesses, and schools. Compatible with PC control software, iPhone/iPod/iPad apps, and high-end control systems, it supports open standards for easy integration.

Key Features

• Control relay-activated devices via TCP/IP Ethernet network
• Compatible with PC software and iOS control apps
• Integrated web server for easy configuration
• Downloadable iHelp utility for simplified network discovery and setup
• Supports IR command capture and playback with iLearn utility
• Three integrated contact closure relays with transient voltage suppression
• Power options include 5 to 16V DC adapter, USB power cable, and optional Power over Ethernet (PoE)
• Compact aluminium extrusion case with rubber end caps
• Complies with FCC, C-tick, CE, and RoHS standards

Specifications

Power Input	5 to 16V DC @ 300mA (wall power adapter included) USB power cable allows power from USB port Power over Ethernet (PoE) unit available (IP2CC-P Specs) International 220V available
Setup	Integrated web server for easy configuration Configure through TCP/IP setup commands
iHelp Setup Utility	Downloadable iHelp software simplifies network discovery and setup
IR Learning Utility	Downloadable iLearn software allows capture and playback of IR commands for control uses
Network Connection	RJ45 Connector 100/10 Mbits Ethernet Protocol Adheres to TCP, DHCP, and HTTP standards
LED Indicators	Power and connector activity indicators
Contact Closure/Relay	3 integrated contact closure relays with transient voltage suppression Pluggable screw terminal 24V AC/DC @ 0.5A N.O. contact Allows switching of low voltage wiring
Device Packaging	Aluminium extrusion case, rubber end caps, and plastic face plates Dimensions (LxWxH): 3.25" x 2.25" x 1.25" Weight: 3.25 oz (6 oz with power supply)
Certifications	FCC (Part 15, Class B), C-tick, CE RoHS compliant
Shipping Box Dimensions	(LxWxH) 9.0" x 3.5" x 2.0" Weight: 1 lb
Warranty	Two year limited warranty Support available via phone, email, and comprehensive support portal

What's in the Box

• Global Cache IP2CC iTach Relay device
• Wall power adapter (5 to 16V DC)
• USB power cable
• User manual and setup guide
