Hikvision WirelessMagnetic Contact

Hikvision DS-PD1-MC-WWS — a 433MHz two-way wireless magnetic door and window contact detector with 800m range for Hikvision security panels.

The Hikvision Wireless Magnetic Contact detects when a door or window is opened and transmits an alert wirelessly to a compatible Hikvision security control panel, which can relay the alarm to a central monitoring station. The dual-reed design improves detection reliability, and the tri-colour LED provides immediate local status feedback. Powered by a CR123A 3V lithium battery rated for approximately two years, it requires no wiring and is quick to install on any door or window frame.

Key features

• 433MHz two-way wireless, 800m range (open area)
• Dual-reed design for improved reliability
• Tri-colour LED status indicator
• Front shell and rear cover tamper switches
• CR123A battery — approx. 2-year life
• No wiring required

Specifications

• Product Code: DSPD1MCWWS
• Transmission Frequency: 433MHz
• Range: 800m (open area)
• Power: CR123A 3.0V lithium (approx. 2 years)
• Operating Temperature: -10°C to +55°C
• Operating Humidity: 10–90%
• Dimensions: 84 × 25 × 21mm
• Weight: 37g

Need help choosing? Contact us at 010 288 2024 or support@audicoonline.co.za.
