InFocus IN0061SL4,000 Lumens True4K

InFocus LightPro Orbital IN0061SL is a True 4K UHD (3840 × 2160) DLP(R) projector delivering 4000 ISO lumens for classrooms, meeting spaces and fixed installations. It uses a 0.47" DMD with XPR technology for 8.3 million on-screen pixels (CTA-approved True 4K UHD).

Key Features

• True 4K UHD 3840 × 2160; Texas Instruments DLP(R) with XPR; 0.47" DMD
• 4000 ISO lumens; contrast ratio 1,000,000:1; UHP lamp, up to 15,000 hours lamp life
• 1.3× manual optical zoom; throw/projection factor 1.21-2.59:1; projection distance 1.0-8.1 m
• Dual HDMI 2.0 (HDCP 2.2), VGA, analogue audio in; USB-A 5 V / 1.5 A power for streaming sticks; S/PDIF optical audio out; RS-232
• Four-corner / ±30° horizontal & vertical keystone; HDR and HLG compatible; ISF modes; full 3D
• Gaming: 1080p 240 Hz support with 4.2 ms input lag (per datasheet feature text)

Applications

Orbital is positioned for bright, detailed imaging in classrooms, meeting rooms and fixed installs, with Smart Ready HDMI for Chromecast, Fire TV, Apple TV or Roku-class sticks powered from the USB-A port.

Specifications

Source: InFocus IN0061SL manufacturer datasheet (official product literature PDF).


Projection technology	Texas Instruments DLP(R)
Native resolution	4K UHD (3840 × 2160)
Panel size	0.47" DMD
Pixels	3840 × 2160
Aspect ratio	16:9
Contrast ratio	1,000,000:1
Brightness	4000 ISO lumens
Light source	UHP lamp
Light source life (maximum)	15,000 hours
Maximum supported resolution	3840 × 2160
Horizontal sync range	15-150 kHz
Vertical sync range	24-240 Hz
Uniformity	80%

Optical

Lens / optical zoom	1.3× / 1.3:1 (manual zoom and focus)
Image offset	115%
Focal length	12.81-16.74 mm
F-stop	2.43
Keystone	Manual/Automatic; vertical ±30°; horizontal ±30° (four-corner)
Projection factor	1.21-2.59:1 (as printed on datasheet)
Projection distance	1.0-8.1 m (3.2-26.6 ft)
Digital zoom	0.8× - 2.0×

Connectivity

Inputs	2× HDMI 2.0 (HDCP 2.2); Mini D-sub 15-pin (VGA); 3.5 mm stereo mini jack
Outputs	3.5 mm stereo mini jack; USB-A power 5 V 1.5 A; S/PDIF optical audio
Control	RS-232
3D	Full 3D, all major formats

Power and general

Power supply	100-240 V AC; 50-60 Hz
Power consumption (max / min)	300 W / 210 W
Standby	<0.5 W
Product dimensions (L × W × H)	313 × 234 × 96.4 mm
Product weight	3.2 kg
Fan noise	27 dB
Built-in audio	1 × 10 W
Operating temperature	0-40 °C
Operating humidity	10-80%
Max operating altitude	3048 m
Security	Kensington Security SlotTM; PIN code lock & timer
Safety / regulatory	CB, CE, EAC, cTUVus, CCC, FCC, UKCA
Environmental	WEEE, EU RoHS, China RoHS

Datasheet

Public manufacturer documents (link only - this does not add a downloads module):

• InFocus IN0061SL product page
• InFocus IN0061SL manufacturer datasheet (PDF)
