Lightware MX2-4X4-HDMI20-CA

Lightware MX2-4X4-HDMI20-CA HDMI 2.0 Matrix Switcher

The Lightware MX2-4X4-HDMI20-CA is a professional 4x4 HDMI 2.0 matrix switcher designed for demanding AV environments such as conference rooms, control centres, and high-resolution digital signage. It delivers seamless switching with support for 4K UHD at 60Hz, 4:4:4 colour sampling, and HDR, ensuring outstanding video and audio performance.

Key Features

• Four HDMI 2.0 inputs and four HDMI 2.0 outputs supporting up to 4K UHD @ 60Hz with 4:4:4 colour sampling
• Supports HDR and full 18 Gbps bandwidth per channel for future-ready performance
• Clear Audio technology with pristine audio pass-through supporting Dolby TrueHD and DTS-HD Master Audio
• HDCP 2.2 compliance on all ports for encrypted content compatibility
• Compatible with both DVI and HDMI components
• Intuitive web-based control interface, IR and RS-232 remote support
• Comprehensive EDID management for easy device integration
• Compact, professional-grade chassis suitable for rack mounting
• Seamless switching with low-latency signal distribution and multiroom AV capabilities
• Robust build designed for reliable 24/7 operation in mission-critical applications

Specifications

• Model: MX2-4X4-HDMI20-CA
• Inputs: 4 x HDMI 2.0
• Outputs: 4 x HDMI 2.0
• Maximum Resolution: 4K UHD (3840x2160) @ 60Hz, 4:4:4 colour sampling
• HDR Support: Yes
• Audio Formats Supported: Dolby TrueHD, DTS-HD Master Audio
• HDCP Compliance: HDCP 2.2
• Control Interfaces: Web-based GUI, IR, RS-232
• Bandwidth: Full 18 Gbps per channel
• Chassis: Compact, rack-mountable professional-grade
