Asus Prime A520M-KAMD AM4 Micro-ATXMotherboard

Asus Prime A520M-K — AMD A520 chipset Micro-ATX motherboard for AM4 Ryzen processors, with dual DDR4, M.2, SATA storage, and HDMI + VGA integrated graphics output.

The Prime A520M-K is an entry-level AM4 platform suitable for Ryzen 5000, 3000, and 2000 series processors. Two DDR4 DIMM slots accommodate up to 64GB of memory, and the M.2 slot (SATA + PCIe x4) alongside four SATA 6Gb/s ports gives flexible storage options. ASUS’s reliability engineering and Realtek Gigabit LAN round out a dependable, no-frills build platform.

Key features

• AMD A520 chipset, AM4 socket
• Supports Ryzen 5000 / 3000 / 2000 series AM4 processors
• 2 × DDR4 DIMM, up to 64GB
• HDMI 2.0 (4K@60Hz) + D-Sub (VGA) integrated graphics output
• 1 × M.2 (SATA + PCIe 3.0 x4) + 4 × SATA 6Gb/s
• Realtek 1Gb Ethernet
• USB 3.2 Gen 1 + USB 2.0 rear and internal headers

Specifications

• Model: 90MB1500-M0EAY0
• Chipset: AMD A520
• Socket: AM4
• Form factor: Micro-ATX
• Memory: 2 × DDR4 DIMM, max 64GB
• Storage: 1 × M.2 (SATA + PCIe 3.0 x4, type 2242/2260/2280), 4 × SATA 6Gb/s
• Display output: 1 × HDMI 2.0 (4K@60Hz), 1 × D-Sub (VGA)
• LAN: Realtek 1Gb (RTL8111H)
• USB (rear): 4 × USB 3.2 Gen 1, 2 × USB 2.0
• Expansion: 1 × PCIe 3.0 x16, 2 × PCIe 3.0 x1
