ResoluXion RX-WALL001 - 4x4 HDMI 1.4 Seamless Matrix with PIP/POP/Video Wall Support

The ResoluXion RX-WALL001 is a high-performance 4x4 HDMI matrix switcher that supports seamless switching with multiple display modes including Picture-in-Picture (PIP), Picture-out-Picture (POP), and video wall configurations. It offers flexible input options and advanced digital scaling for perfect visual effects and unified output signals.

Key Features

• Compliant with HDMI 1.3, HDCP 1.3, and DVI 1.0 standards
• Supports mixed inputs: HDMI, VGA, and Composite Video (C-video)
• Seamless switching modes: fast switching, fade in/fade out, blinds, and more
• Supports input resolutions up to 1080p for HDMI and VGA inputs
• Supports standard TV formats for Composite Video: PAL, NTSC3.58, NTSC4.43, SECAM, PAL/M, PAL/N
• Output resolution support up to 1920x1080p @ 60Hz
• Advanced scaler function for unified output signal and format conversion
• Flexible control options: front panel buttons, remote control, RS-232, and TCP/IP
• Smart EDID management for optimal compatibility
• Picture adjustment settings and automatic VGA input video adjustment
• Power-off memory to retain settings
• RS-232 port available for firmware updates

Specifications

• Inputs: 4 mixed inputs (HDMI, VGA, Composite Video)
• Outputs: 4 HDMI outputs with seamless switching
• Input Resolutions Supported:
  • HDMI: 480i up to 1080p
  • VGA: 1920x1080p @ 60Hz, 1360x768p @ 60Hz, 1280x1024p @ 60Hz, 1024x768p @ 60Hz, 1280x720p @ 60Hz, 1280x768p @ 60Hz, 800x600 @ 60Hz, 640x480p @ 60Hz
  • Composite Video: PAL, NTSC3.58, NTSC4.43, SECAM, PAL/M, PAL/N
• Output Resolution: 1920x1080p @ 60Hz

What's in the Box

Product image shown below:
