( 01 / 01 )Aten VK108US8-Button ControlSystem
Aten VK108US — fully customisable 8-button wall keypad for the ATEN Control System, fitting a standard US 1-gang wall plate and connecting to a VK Control Box or Control Pad over LAN.
The VK108US gives room occupants instant physical control of AV equipment, lighting, and other connected devices from a wall-mounted keypad. Up to 14 different button layout combinations — using 4 to 8 buttons that snap together like building blocks — allow the keypad to be configured for the specific functions needed in any room. It connects to ATEN VK2200, VK1200, VK2100A, or VK1100A Control Boxes, or to VK0100/VK0200 Control Pads, over a standard LAN connection. All button functions are programmed via the VK6000 Configurator Software without any custom hardware.
Key features
- Fully customisable — 14 layout combinations using 4–8 snap-together buttons
- Standard US 1-gang wall plate form factor
- LAN connection to VK2200/VK1200/VK2100A/VK1100A Control Boxes or VK0100/VK0200 Control Pads
- Programmed via ATEN VK6000 Configurator Software
- Provides instant room control without a touchscreen
Specifications
- Buttons: Up to 8 (4–8 in 14 layout combinations)
- Form factor: US 1-gang wall plate
- Connection: LAN (to VK Control Box or Control Pad)
- Software: ATEN VK6000 Configurator
- Compatible controllers: VK2200, VK1200, VK2100A, VK1100A, VK0100, VK0200
