( 05 / 05 )Tannoy OCV 8 White8" Outdoor CoaxialLoudspeaker

Tannoy OCV 8 White — a weather-resistant 8-inch outdoor coaxial loudspeaker for commercial and installed-sound applications.
The OCV-8-WH is built for permanent outdoor installation where reliable, full-range coverage is required regardless of the elements. The UV-stabilised, weather-resistant ABS enclosure and a coaxially mounted 8-inch mineral-loaded polypropylene driver with a 1-inch soft dome diffraction-loaded tweeter combine to deliver wide-dispersion sound from 60 Hz to 20 kHz. A built-in line transformer with multiple wattage taps allows straightforward connection to 70V or 100V distributed amplification systems. The supplied yoke bracket enables both horizontal and vertical mounting orientations.
8-inch mineral-loaded polypropylene woofer with 1-inch soft dome coaxial tweeter
UV/weather-resistant ABS enclosure for permanent outdoor use
60 Hz – 20 kHz frequency response with wide horizontal dispersion
( Specifications )
| Impedance | 8 Ohms |
| Frequency response | 70 Hz - 20 kHz |
| Recommended Amplifier Power | 70 Watts |
| aimable | No |
| Brand | Tannoy |
| Certifications | CE, RoHS |
| Color | White |
| Compliance Standards | IP64 certified |
| Connectivity | Terminal block |
| Continuous Power Handling | 60 Watts |
| Coverage Angle | Wide |
| Crossover frequency | 2.5 kHz |
| Designed for | Broadcast music and paging |
| Dimensions | 280 x 277 mm |
