Hegel V10 MM andMC PhonoPreAmplifier

Hegel V10 - MM and MC Phono Preamplifier

The Hegel V10 is a premium phono preamplifier designed to deliver neutral, dynamic, and exceptionally revealing sound for both Moving Magnet (MM) and Moving Coil (MC) cartridges. With 30 years of expertise in discrete transistor circuit design, the V10 brings unprecedented transparency and detail to your vinyl listening experience.

Key Features

• Ultra low-noise discrete JFET transistor input stage for both MM and MC cartridges
• Physically separated power supply and amplification circuitry to eliminate interference
• Gold-plated terminals, balanced XLR outputs, and custom grounding screw for optimal connections
• Adjustable MC load impedance (33 to 550 ohms or fixed 47 kohm) and MM load capacitance (100 to 467 pF)
• Multiple gain settings for MM and MC inputs to match your system
• Switchable subsonic filter to remove unwanted low-frequency noise
• Linear, low-noise analog AC power supply with custom E-core transformer in separate housing
• Adjustable auto standby function for energy saving
• Plug-and-play out of the box with full customisation options for audiophiles

The V10’s design focuses on delivering the purest sound by isolating sensitive amplification circuits from power supply interference. The MC input uses four parallel-connected ultra-low-noise JFET transistors to eliminate noise and bias current feedback, ensuring silent operation even with low output MC cartridges. Both MM and MC gain stages feature discrete bipolar transistor power supplies for minimal signal noise and accurate amplification.

The V10 is highly optimisable to suit individual setups. MM capacitance can be adjusted between 100 and 467 pF, while MC impedance is adjustable between 33 and 550 ohms or fixed at 47 kohm. Gain can be increased by 5, 10, or 12 dB on both inputs. The built-in subsonic filter reduces low-frequency rumble, and an adjustable auto standby function conserves power when not in use.

Specifications

• Amplifier Typology: Ultra low noise discrete JFET transistor input stage for MC and MM
• Gain XLR Out MM: 40dB / 45dB / 50dB / 52dB
• Gain XLR Out MC: 60dB / 65dB / 70dB / 72dB
• Gain RCA Out MM: 34dB / 39dB / 44dB / 46dB
• Gain RCA Out MC: 54dB / 59dB / 64dB / 66dB
• MC Load Impedance: Adjustable 33 to 550 ohms / fixed 47 kohm
• MM Load Capacitance: 100pF / 147pF / 220pF / 247pF / 320pF / 420pF / 467pF @ 47 kohm
• Subsonic Filter: Switchable on/off, -3dB at 20Hz, -18dB/octave
• RIAA Accuracy: ±0.2dB (20Hz – 20kHz)
• Output Noise*: -84dB/MM (“A” weighted ref: 0dBV), -81dB/MC (“A” weighted ref: 0dBV)
• Output Impedance XLR / RCA: 200 ohm
• Channel Crosstalk: -84dB @1kHz 0dBV
• Frequency Response: 2Hz – 20kHz
• Distortion (THD) MM: < 0.005% @1kHz 0dBV
• Distortion (THD) MC: < 0.009% @1kHz 0dBV
• Inputs: 1 x unbalanced (RCA) MM, 1 x unbalanced (RCA) MC
• Outputs: 1 x unbalanced fixed (RCA), 1 x balanced fixed (XLR)
• Power Adapter: Hegel Power Adapter M30103
• Dimensions with Feet: 6cm x 21cm x 28cm (H x W x D)
• Weight: 2.2kg / 4.9lbs
• *When stable operating temperature has been reached
