HikvisionDS-2CE76D0T 2MPIndoor

Hikvision DS-2CE76D0T-EXIPF — 2 MP indoor fixed turret camera with up to 20 m IR night vision and switchable TVI/AHD/CVI/CVBS output.

The Hikvision DS-2CE76D0T-EXIPF delivers sharp 1920×1080 indoor surveillance with a 2 MP CMOS sensor and automatic IR Cut Filter for reliable day and night imaging. Available with a 2.8 mm or 3.6 mm fixed focal lens to suit different room sizes, its single-port quad-signal output (TVI/AHD/CVI/CVBS) provides broad DVR compatibility. Digital WDR and 2D DNR noise reduction ensure clear imagery in challenging lighting conditions.

Key features

• 2 MP CMOS sensor, 1920×1080 resolution
• Up to 20 m IR night vision range
• Choice of 2.8 mm (96.5° HFOV) or 3.6 mm (76.9° HFOV) fixed lens
• Switchable TVI/AHD/CVI/CVBS output on one port
• ICR day/night switching
• Digital WDR and 2D DNR noise reduction
• Pan 0–360°, tilt 0–75°, rotate 0–360°
• Operating range: −40°C to 60°C

Specifications

• Model: DS-2CE76D0T-EXIPF
• Sensor: 2 MP CMOS
• Resolution: 1920 (H) × 1080 (V)
• Min. illumination: 0.02 Lux (F1.2, AGC ON); 0 Lux with IR
• Lens: 2.8 mm or 3.6 mm fixed (M12)
• IR range: Up to 20 m
• Video output: Switchable TVI/AHD/CVI/CVBS
• Frame rate: 1080p @ 25/30 fps
• Power: 12 VDC ±25%, max 3.3 W
• Dimensions: Ø84.6 × 78.9 mm
• Weight: Approx. 195 g
• Operating temperature: −40°C to 60°C
